2-stage compressor general aprameter list
| Two-stage PM VSD screw air compressor | |||||||||||
| MODEL | Air flow (m3/min) | power (kw) | Noise (Db) | Discharge connection | Dimension ( mm) | Weight (KG) | |||||
| 0.7Mpa | 0.8Mpa | 1.0Mpa | 1.3Mpa | Length | Width | Height | |||||
| RMC-VPM2T22 | 4.50 | 4.20 | 3.40 | 2.60 | 22 | 68 | G1 | 1440 | 830 | 1265 | 840 |
| RMC-VPM2T30 | 6.05 | 5.80 | 4.18 | 4.00 | 30 | 68 | G11/2 | 1500 | 940 | 1415 | 900 |
| RMC-VPM2T37 | 7.40 | 7.13 | 6.00 | 4.60 | 37 | 68 | G11/2 | 1500 | 940 | 1415 | 950 |
| RMC-VPM2T45 | 10.50 | 9.90 | 6.80 | 5.71 | 45 | 72 | G2 | 2000 | 1120 | 1590 | 1360 |
| RMC-VPM2T55 | 13.60 | 12.30 | 10.15 | 7.00 | 55 | 76 | DN50 | 2900 | 1470 | 1625 | 1780 |
| RMC-VPM2T75 | 16.00 | 15.50 | 12.80 | 10.20 | 75 | 76 | DN50 | 2900 | 1470 | 1625 | 2000 |
| RMC-VPM2T90 | 20.70 | 19.50 | 16.15 | 13.20 | 90 | 76 | DN65 | 3400 | 1757 | 1860 | 2700 |
| RMC-VPM2T110 | 24.80 | 24.00 | 20.20 | 15.21 | 110 | 76 | DN65 | 3400 | 1757 | 1860 | 3000 |
| RMC-VPM2T132 | 29.00 | 28.00 | 23.20 | 18.70 | 132 | 78 | DN80 | 3750 | 1900 | 1980 | 4650 |
| RMC-VPM2T160 | 34.00 | 32.50 | 28.00 | 23.10 | 160 | 78 | DN80 | 3750 | 1900 | 1980 | 4850 |
| RMC-VPM2T185 | 39.00 | 38.00 | 32.00 | 27.70 | 185 | 78 | DN100 | 3900 | 2100 | 1980 | 5900 |
| RMC-VPM2T200 | 43.20 | 42.00 | 38.10 | 31.90 | 200 | 78 | DN100 | 3900 | 2100 | 1980 | 6200 |
| RMC-VPM2T220 | 48.51 | 46.20 | 41.20 | 31.60 | 220 | 82 | DN100 | 4260 | 2182 | 2170 | 6200 |
| RMC-VPM2T250 | 51.80 | 51.00 | 45.80 | 37.20 | 250 | 82 | DN100 | 4260 | 2182 | 2170 | 6500 |
